Item | Description |
Image Sensor |
CMOS 1/3 |
Output formats |
PAL/NTSC |
Effective Pixel Array |
1280(H) x 720(V) AHD – 733(H) x 493 (V) CVBS |
Resolution |
1.0MP |
Day and Night Mode |
Colour |
Video Amplitude |
AHD/CVBS |
Day/Night Mode |
Auto |
Video Signal |
AHD/CVBS |
Exposure |
Auto |
Gain Control |
Auto |
White Balance |
ATW |
Min. Illumination |
0.02Lux@(F1.2,AGC ON) |
Wide Angle Diagonal |
170° |
View Angle |
Horizontal 140° |
Vertical 100° |
Image Character |
One switchable line: AHD PAL or CVBS NTSC switchable |
Working Voltage |
12V DC |
Working Current |
80±10mA |
Working Voltage Range |
9~15V DC |
Working Temperature |
-25~+70°C |
Storage Temperature |
-30~+75°C |
Image Quality Assurance Temperature |
-25~+70°C |
Environment Humidity |
90%RH |
Waterproof Grade |
IP68 |
