Description Not Available
| Item | Description |
|---|---|
| Image Sensor | CMOS 1/3 |
| Output formats | PAL/NTSC |
| Effective Pixel Array | 1280(H) x 720(V) AHD – 733(H) x 493 (V) CVBS |
| Resolution | 1.0MP |
| Day and Night Mode | Colour |
| Video Amplitude | AHD/CVBS |
| Day/Night Mode | Auto |
| Video Signal | AHD/CVBS |
| Exposure | Auto |
| Gain Control | Auto |
| White Balance | ATW |
| Min. Illumination | 0.02Lux@(F1.2,AGC ON) |
| Wide Angle Diagonal | 170° |
| View Angle | Horizontal 140° |
| Vertical 100° | |
| Image Character | One switchable line: AHD PAL or CVBS NTSC switchable |
| Working Voltage | 12V DC |
| Working Current | 80±10mA |
| Working Voltage Range | 9~15V DC |
| Working Temperature | -25~+70°C |
| Storage Temperature | -30~+75°C |
| Image Quality Assurance Temperature | -25~+70°C |
| Environment Humidity | 90%RH |
| Waterproof Grade | IP68 |
